Rack Mount Sliding Fiber Optic Patch Panel with LC Duplex Adapters, 1U Height, FPP124 Series

Original price USD $98.00 - Original price USD $153.00
Original price
USD $98.00 (Excl. GST)
USD $106.82 (Incl. GST)
USD $98.00 - USD $153.00
Current price
USD $98.00 (Excl. GST)
USD $106.82 (Incl. GST)

General Description

The LC duplex rack mount sliding fiber optic patch panel from the FPP124 series is an ideal solution for the secure and organized storage of optical fibers. It comes pre-loaded with LC duplex fiber optic adapters and a splice management kit, which ensures easy installation and maintenance.

One of the most notable features of this patch panel is its adjustable sliding working tray, which can be set to different working angles ranging from 10 degrees to 45 degrees, making the network cable connections easily accessible even when the panel is installed on server racks. Additionally, the top cover can be removed to support optical installation and maintenance works.


FPP124 Series Removable Top Cover


Removable top cover for FPP124 series with LC duplex adapter
Features
  • Support both Singlemode or multimode LC duplex adapter type
  • Splice management accessories such as spools, cable glands, splice trays
    and splice sleeves are provided
  • Recessed panel option
  • Mounting option available: Protruding or Recessing
  • 4 cable entries (20mm) with cable gland and dust cover
  • 4 clamping system to secure strength members from the fiber optic cables

    Specifications

    Dimension: 44mm Height  x 482mm Width  x  230mm Depth

    Mounting Adjustment Range: 50mm

    Material & Coating: Aluminium, Electro-Static Powder Coating

    Material Thickness: 1.5mm

    IP Rating: IP20

    Colour: Black RAL 9004

    Weight: 1.8kg (without packaging)

    Operating Temperature: -20 degrees Celsius to 70 degrees Celsius

    Standards comply: TIA/EIA 568.C, ISO/IEC 11801, EN 50173, IEC 60304, IEC 61754, EN 297-1

    Additional Product Information: The FPP124 Series Rack Mount Patch Panel with LC duplex adapters will be loaded with LC duplex adapters (according to the number of ports specified), 1 to 2 splice trays (one splice tray can support up to 24 ports),  1 set of spools, 4 cable glands and splice sleeves (according to the number of ports specified).


    Accessories for FPP124 Series Rack Mount Fiber Optic Patch Panel
